fecowand

Pleasure for both eyes and ears.

Its versatility makes the partition wall a classic. Melamine, laminate, veneer, textile or metal, standard or high sound insulation, with or without fire resistance – whatever version you are selecting, the visual impression is perfect. So is the acoustic quality, because even the basic version of fecowand achieves a sound insulation of R_w,P = 47 dB. Of course in all fire resistance ratings up to EI90.

Only with the patented feco clip system the wall panels are invisibly clipped to the partition wall uprights by means of clip rails running along the entire length. The advantages as compared to a simple point fixture are:

Improved stability
The inserted full-length clip rails form a solid connection with the partition wall upright, thereby increasing the strength. Proved by tests according to DIN 4103.

More exact joints
At the same time the partition wall panels are fixed in respect of lateral displacement. This ensures longitudinal stability and foremost a precise joint pattern.

Higher acoustic insulation
The full-length solid connections between the partition wall panels and the substructure result in excellent acoustic insulation.

Downloads and Info

fecowand - Brochure Technical product overview fecowand - Technology brochure

Product attributes

Moveable modular partition wall as solid wall
Wall thickness 105 mm, for special versions 125-175 mm
Slender 6 mm shadow gap between the elements
Concealed fixture of all wall panels
Recessed connections on floor, wall and ceiling
Integrated negative base, no skirting board required
Smooth ceiling connection as standard
Substructure from system steel profiles
Insulation with bio-soluble mineral fibrous sheet
Covering from wood-based material, usually three-layered quality chipboard (for EI90 plaster composite materials)
Standard surface finished with direct melamine resin coating, optionally laminate, real wood veneer, metal, fibreglass fabric, textile or varnish
High level of prefabrication ensures short installation times
Exceptionally high acoustic insulation by means of patented feco clip system with full-height clip rails
Sound insulation test certificates for solid wall R_w,P = 47 dB up to 52 dB
Fire resistance of solid wall EI30 up to w x h = 1.50 x 4.00 m
Fire resistance of solid wall EI90 up to w x h = 1.25 x 3.00 m
